Digital Ultrasonic DPF Cleaner Vehicle Engine Repair Carbon Emission System

Brand Name : OURS ULTRASONIC

Model Number : ARS-DQXJ-1024

Certification : CE,RoHS,CSA,FCC

Place of Origin : China

MOQ : 1SET

Price : USD1280-USD1680

Payment Terms : T/T, Western Union PAYPAL

Supply Ability : 2000set month

Delivery Time : 3-5 days

Packaging Details : Carton box or plywood box

Use : engineer parts cleaning

power : 300w-3000w

Voltage : 110V and 220V

Condition : new

Application : ultrasonic cleaning machine

Contact Now

Automatic vehicle engine repair carbon emission system ultrasonic DPF Cleaner

Working mechanism:

The workpiece to be cleaned is put into the material frame, and the material frame is put on the material inlet manually, and the multi arm mechanical arm moves the material frame to the corresponding station according to the program specified by PLC; after the cleaning, rinsing, rinsing, suction drying and vacuum drying of the workpiece, it is sent to the discharge platform for discharging. The multi arm manipulator is horizontally driven by the cylinder and guided by the linear slide rail; the up and down lifting is driven by the motor and guided by the linear guide shaft; the touch screen operating system is adopted, with manual and automatic switch and related operation buttons, which can control the whole operation process.

Type Internal size
L*W*H (mm)		 Outsize mm
L*W*H (mm)		 Frequency (Khz)

Power
(W)

Heating
(W)

 Total power(W) voltage
ARS-DQXJ-1006 280×210×210 320×250×350 20,28,33,40,80,130 300 1000 1300 220V
ARS-DQXJ-1012 400×310×280 520×430×600 20,28,33,40,80,130 600 3000 3600 220V
ARS-DQXJ-1018 490×360×320 610×480×675 20,28,33,40,80,130 900 3000 3900 220V
ARS-DQXJ-1024 630×430×320 740×550×675 20,28,33,40,80,130 1200 4000 5200 220V
ARS-DQXJ-1030 630×530×320 750×650×675 20,28,33,40,80,130 1500 4000 5500 220V
ARS-DQXJ-1036 680×530×360 800×650×700 20,28,33,40,80,130 1800 5000 6800 220V
ARS-DQXJ-1040 680×570×400 830×710×735 20,28,33,40,80,130 2000 5000 7000 220V
ARS-DQXJ-1041 730×570×450 880×710×735 20,28,33,40,80,130 2400 6000 8400 220V
ARS-DQXJ-1042 790×670×510 940×765×785 20,28,33,40,80,130 3000 6000 9000 380V
ARS-DQXJ-1043 850×770×570 990×820×785 20,28,33,40,80,130 4000 7000 11000 380V
ARS-DQXJ-1044 910×820×620 1050×880×840 20,28,33,40,80,130 5000 7000 12000 380V
ARS-DQXJ-1045 960×870×680 1100×940×920 20,28,33,40,80,130 8000 8000 16000 380V
ARS-DQXJ-1046 1100×930×730 1160×1000×980 20,28,33,40,80,130 10000 8000 18000 380V


Digital Ultrasonic DPF Cleaner Vehicle Engine Repair Carbon Emission System

Automatic vehicle engine repair carbon emission system ultrasonic DPF Cleaner
