ultrasonic transducer parts cleaner 1000Watt/2000Watt/28khz/40khz
1. Small ultrasonic cleaner
It is used in optics, glasses, watch parts, miniature bearings, electric vacuum devices, semiconductor devices, missile guidance system, etc. which require high cleaning quality.
2. Multi tank ultrasonic cleaner
Cleaning working time can be set and adjusted. According to the specific cleaning work, the stainless steel basket is equipped to achieve better cleaning effect.
3. Ultrasonic cleaning machine for small parts
It is applicable to the cleaning of small parts in various industries, especially the cleaning of small magnetic blocks in the magnetic industry.
4. Bearing ultrasonic cleaning machine
According to the special requirements of users, we can customize all kinds of special ultrasonic cleaning equipment and production lines, plug-in lines, assembly lines.
5. Crawler type ultrasonic cleaner
It is suitable for continuous and large-scale cleaning of mechanical parts, ultrasonic cleaning equipment, industrial devices and magnetic materials.
6. Chain type ultrasonic cleaning dryer
The special stainless steel chain drive is used to clean the workpiece. After ultrasonic cleaning and spray rinsing, the cleaning effect is achieved.
After knowing the cleaning objects of the above-mentioned cleaning machine, it is necessary to know some parameters when purchasing the cleaning machine, so as to buy the appropriate cleaning equipment for cleaning various objects. The parameter here is frequency. The following editor will tell you which items can be cleaned at different frequencies.
At present, the frequency applied in the ultrasonic cleaning instrument can be as high as 200K. The lower the ultrasonic frequency, the greater the roughness of the cleaning object, but the strength will be enhanced, so the lower the frequency is suitable for cleaning metal objects such as hardware. The higher the frequency, the higher the cleaning accuracy, but the strength will be weak, suitable for cleaning precision electronic parts. 20khz-28khz is a lower frequency band, 40khz-80khz is a medium frequency band, and above 80kHz is a high frequency band. For cleaning general objects, such as hardware, circuit board, nozzle, auto parts, etc., the medium frequency is applicable. Therefore, the general standard machine in the industry adopts the frequency of 40KHz, and most objects can be applied.
| Type | Internal size
L*W*H (mm) | Outsize mm
L*W*H (mm) | Frequency (Khz) | Power (W) | Heating (W) | Total power(W) | voltage |
| ARS-DQXJ-1006 | 280×210×210 | 320×250×350 | 20,28,33,40,80,130 | 300 | 1000 | 1300 | 220V |
| ARS-DQXJ-1012 | 400×310×280 | 520×430×600 | 20,28,33,40,80,130 | 600 | 3000 | 3600 | 220V |
| ARS-DQXJ-1018 | 490×360×320 | 610×480×675 | 20,28,33,40,80,130 | 900 | 3000 | 3900 | 220V |
| ARS-DQXJ-1024 | 630×430×320 | 740×550×675 | 20,28,33,40,80,130 | 1200 | 4000 | 5200 | 220V |
| ARS-DQXJ-1030 | 630×530×320 | 750×650×675 | 20,28,33,40,80,130 | 1500 | 4000 | 5500 | 220V |
| ARS-DQXJ-1036 | 680×530×360 | 800×650×700 | 20,28,33,40,80,130 | 1800 | 5000 | 6800 | 220V |
| ARS-DQXJ-1040 | 680×570×400 | 830×710×735 | 20,28,33,40,80,130 | 2000 | 5000 | 7000 | 220V |
| ARS-DQXJ-1041 | 730×570×450 | 880×710×735 | 20,28,33,40,80,130 | 2400 | 6000 | 8400 | 220V |
| ARS-DQXJ-1042 | 790×670×510 | 940×765×785 | 20,28,33,40,80,130 | 3000 | 6000 | 9000 | 380V |
| ARS-DQXJ-1043 | 850×770×570 | 990×820×785 | 20,28,33,40,80,130 | 4000 | 7000 | 11000 | 380V |
| ARS-DQXJ-1044 | 910×820×620 | 1050×880×840 | 20,28,33,40,80,130 | 5000 | 7000 | 12000 | 380V |
| ARS-DQXJ-1045 | 960×870×680 | 1100×940×920 | 20,28,33,40,80,130 | 8000 | 8000 | 16000 | 380V |
| ARS-DQXJ-1046 | 1100×930×730 | 1160×1000×980 | 20,28,33,40,80,130 | 10000 | 8000 | 18000 | 380V |
